QFP stats no longer showing up

Help
1

Hi,

We have a Cisco ASR1K which has Quantum Flow Processor and it was always very well graphed in LibreNMS. Unfortunately recently it dissapearead from health tab for the device. But if we go to the URL directly /device/device=6/tab=health/metric=qfp/ it shows all the metrics we are looking for. Now the only metric showing up is /device/device=6/tab=health/metric=processor/

Would you know how to bring it back? Not sure if it is related in any way but we are getting a lot of mess in event log:

|2021-03-26 21:25:16|component|[gw0]/device/6)|Component: cisco-qfp(129). Attribute: average_packet, was modified from: 1072.7279379999, to: 1079.7552203553|System|
|2021-03-26 21:25:16|component|[gw0]/device/6)|Component: cisco-qfp(129). Attribute: throughput, was modified from: 5879922192, to: 5785604888|System|
|2021-03-26 21:25:16|component|[gw0]/device/6)|Component: cisco-qfp(129). Attribute: packets, was modified from: 685160, to: 669782|System|
|2021-03-26 21:25:16|component|[gw0]/device/6)|Component: cisco-qfp(129). Attribute: utilization, was modified from: 23, to: 21|System|
|2021-03-26 21:20:19|component|[gw0]/device/6)|Component: cisco-qfp(129). Attribute: average_packet, was modified from: 1059.3708439753, to: 1072.7279379999|System|
|2021-03-26 21:20:19|component|[gw0]/device/6)|Component: cisco-qfp(129). Attribute: throughput, was modified from: 6005954688, to: 5879922192|System|
|2021-03-26 21:20:19|component|[gw0]/device/6)|Component: cisco-qfp(129). Attribute: packets, was modified from: 708670, to: 685160|System|
|2021-03-26 21:20:19|component|[gw0]/device/6)|Component: cisco-qfp(129). Attribute: utilization, was modified from: 22, to: 23|System|

And it shows up in log in every 5 mins. Any tips will be greatly appreciated

Thanks and regards,
Michal

2

The component stuff is normal. It happens every time a new value is polled. So that shows polling is still going on as expected.

Issue is only in the GUI.

Any chance you could try to find the approx date it changed, and check in the code changes that occured arround that date ?

3

Hi,

It would seem that it all started around 24th March around midnight. Please also note that the event log wasn’t containing such entries before. It looks very unusual and no other device is showing similar log entries (although we only have one ASR so no way to compare))

Kind regards,
Michał

4

I would guess that you are on “Master” and that the behaviour you have might be linked to this patch :

Unfortunately I have no way to reproduce your issue, so we’ll need you to dig a little bit in the code to find out what might be the issue here.

5

If you go to the global health page and filter to that device, do they still show up?

6

Hi,

When I click Health, choose Processor (because there is no QFP on the list) and then filter to find the device I get two graphs - cpu R0/0 and qfp R0/0. So much less than it shows when I visit the link directly (/tab=health/metric=qfp/).

Kind regards,
Michał

7

A little bump to this topic,

We are currently running 3 devices (Cisco ISR4331 & 2x Cisco ASR1001-X) with QFP and the mountain of messages in the Eventlog are quite annoying (4 messages on 3 devices every 5 minutes).

And if more information is needed, pleas ask
